DynamicRoll Food Inox High Speed Door

DynamicRoll Food Inox High Speed Door - Image 2

DynamicRoll Food Inox High Speed Door - Image 3

DynamicRoll Food Inox High Speed Door - Image 4

DynamicRoll Food Inox High Speed Door

Full stainless steel construction high speed door for food processing and hygiene-critical environments, rated IP65 with washdown resistance, inverter control and a self-repairing PVC curtain.

Category: Dynamic Roll Self Repairing High Speed Doors Tags: Dockleveller Supplies, Door-Rite Range, food inox high speed door, food safe industrial door, hygiene controlled access door, insulated food processing door, pvc high speed door, stainless steel rapid door Brand: Door-Rite

Need a Quote or Door Advice?

Our Door-Rite specialists can assist with door selection, sizing, installation planning, and compliance requirements across South Africa and Africa.

Speak to an Engineer →

The DynamicRoll Food Inox High Speed Door is engineered for environments that demand strict hygiene control, fast access and easy cleaning. Constructed entirely from stainless steel, it is suitable for food processing areas, clean production zones and any internal space where corrosion resistance and sanitary operation are essential.

The PVC curtain provides rapid opening and closing to help maintain temperature stability and reduce airborne contamination. The stainless steel frame, covers and hardware ensure resistance to frequent washdowns, cleaning chemicals and the harsh conditions found in food production and pharmaceutical environments.

General

Designed for internal food-grade and hygiene-critical environments
Rapid operation for efficient workflow and temperature control
Stainless steel frame and covers for corrosion resistance
Suitable for frequent washdowns and sanitation procedures
Curtain available in multiple colours including insulated variants
Application classified as internal

Dimensions and Performance

Maximum standard dimensions: 3,500 mm W × 4,000 mm H
Opening speed: up to 2 m/s
Closing speed: approximately 0.6 m/s
Wind resistance: Class 0 (internal use only)
Operating temperature range: −30°C to +70°C

Structure

Stainless steel AISI 304 as standard; AISI 316 available on request
Side guides designed for hygiene and low friction movement
Reels in galvanised steel or stainless steel AISI 304
Compact frame dimensions for restricted installations
Modular design for simplified service and maintenance

Curtain

PVC curtain with smooth coated surfaces for easy cleaning
Standard weight: approximately 1,300 g/m² in 12 available colours
Insulated or FDA-approved curtain options available
Vision panel configurations available in dual-row arrangement

Motor and Control

Motor rating: 0.75 kW to 1.5 kW depending on size
Protection rating: IP65 for motor and control components
Inverter-driven control panel with PVC or stainless steel enclosure
Single phase 220 V power supply
Digital encoder for precise positioning

Safety Features

Electronic crushing protection system IP65 rated
Infrared photocells integrated into vertical columns, IP65 rated
Resistive safety edge option available
Manual emergency operation via rod handle or UPS system
