Food-grade PE high speed door

High speed door with polyethylene (PE) frame for food-safe, hygiene-critical environments. Chemical resistant, easy to clean, with IP65 rated controls and a rapid-action PVC curtain.

Need a Quote or Door Advice?

Our Door-Rite specialists can assist with door selection, sizing, installation planning, and compliance requirements across South Africa and Africa.

Speak to an Engineer →

The Dynamic Roll Food PE High Speed Door is designed specifically for hygiene-controlled industrial environments where cleanability, durability and ease of maintenance are essential. Constructed from food-safe polyethylene (PE) with corrosion-resistant components, it is ideally suited for food processing facilities, prep rooms, experimental laboratories and any application requiring high sanitation standards.

The flexible PVC curtain delivers fast opening and closing cycles to reduce air transfer and maintain stable internal conditions. The smooth surfaces of the PE frame components allow for thorough cleaning using standard washdown procedures, without degradation from exposure to cleaning agents or moisture.

General

  • Designed for internal hygiene-critical and food-grade environments
  • PE (polizene) frame construction for full chemical resistance
  • Smooth surfaces for easy cleaning and low maintenance
  • Suitable for frequent washdown and sanitation procedures
  • Intended for high cycle usage in clean prep rooms and food processing areas
  • Internal-only wind resistance classification

Dimensions and Performance

  • Maximum standard dimensions: 3,500 mm W × 4,000 mm H
  • Opening speed: up to 2 m/s
  • Closing speed: approximately 0.6 m/s
  • Wind resistance: Class 0 (internal applications only)
  • Operating temperature range: −30°C to +70°C

Structure

  • Polyethylene (PE) lateral uprights with corrosion and chemical resistance
  • Optional stainless steel AISI 304 or AISI 316 components for enhanced hygiene
  • Reels in galvanised steel or stainless steel AISI 304
  • Modular construction for ease of servicing

Curtain

  • PVC curtain designed for fast movement and low air exchange
  • Smooth coated surface for sanitation and washdown compatibility
  • Available in 12 standard colour options
  • Optional insulated or FDA-approved curtain variants
  • Vision panels available in various configurations

Motor and Control

  • Motor protection rating: IP65
  • Motor power range: 0.75 kW to 1.5 kW depending on door size
  • Inverter-driven control panel for smooth acceleration and deceleration
  • Control panel casing: PVC (IP65) or stainless steel AISI 304
  • Powered by single-phase 220 V supply
  • Digital encoder for precision control

Safety Features

  • Electronic crushing protection system IP65
  • Infrared photocells integrated into the columns, IP65 rated
  • IP65 rated control button
  • Manual emergency operation by rod handle or optional UPS system
