Dynamic Roll High Speed Door with PVC curtain and galvanised steel frame designed for rapid industrial operation.

Dynamic Roll High Speed Door

Rapid-action industrial door with a self-repairing PVC curtain and galvanised steel frame, designed for continuous high-cycle use across manufacturing, food production and logistics environments.

Need a Quote or Door Advice?

Our Door-Rite specialists can assist with door selection, sizing, installation planning, and compliance requirements across South Africa and Africa.

Speak to an Engineer →

The Dynamic Roll High Speed Door is a rapid action industrial door designed for fast, efficient movement between operational areas while maintaining environmental control. Its flexible PVC curtain, guided within a galvanised steel frame, allows for high cycle use and reduced air exchange, making it ideal for manufacturing facilities, warehousing, food production zones and temperature-sensitive environments.

The system is engineered for continuous operation, with inverter-controlled motor technology that enables smooth, high speed movement. A modular design ensures ease of maintenance, and a wide range of curtain colours, thicknesses and safety integrations allows the door to be configured for diverse industrial requirements.

General

Rapid opening and closing for workflow efficiency
Designed for intensive, continuous industrial service
Suitable for internal or external applications depending on configuration
Curtain available in a range of PVC colours including insulated options
Vision panels available in various layouts for improved visibility
Operating temperature range: −30°C to +70°C
Structure built for low maintenance operation

Structure

Galvanised metal frame with shaped side rails
Low friction self-lubricating guide system
Steel case control panel
Modular design for easy maintenance
Optional stainless steel frame configurations available

Curtain

PVC curtain with coated surface on both sides
Curtain weight: approximately 1,300 g/m² depending on model
Multiple colour options available
Optional insulated curtain (3 mm) for enhanced thermal performance
Optional FDA-approved curtain available for hygiene-sensitive environments

Motor and Control

Three-phase brake motor for continuous service with inverter control
Motor speeds: up to 2 m/s depending on configuration
Digital encoder for accurate door positioning
Control panel: 300 mm W × 400 mm H × 150 mm D
Single phase or three phase supply depending on size

Performance

Opening speed: up to 2 m/s
Wind resistance: up to Class 2 depending on size
Maximum width: 8,000 mm; maximum height: 7,000–8,000 mm depending on configuration
Thermal performance: approximately 5.82 W/m²K depending on curtain type
