Cube Stacking Doors

Space-saving sectional door with compact stacking installation depth, ideal for sites with crane tracks or limited overhead clearance. Available in aluminium A40 or combined aluminium/steel S40 sections.

Need a Quote or Door Advice?

Our Door-Rite specialists can assist with door selection, sizing, installation planning, and compliance requirements across South Africa and Africa.

Speak to an Engineer →

The CUBE Stacking Door is a high performance solution for locations where installation depth is limited. Its sections fold and stack compactly behind the opening, making it ideal for sites where traditional overhead door tracks cannot be accommodated. The system can be manufactured in aluminium A40 sections or a combination of aluminium and steel S40 sections, allowing for significant design flexibility while maintaining strength and durability.

The lightweight aluminium construction supports a long and trouble-free operating life, while maintaining a refined architectural appearance. A wide range of panel fillings including windows, glass, open or blank variants allows the door to suit both functional and aesthetic requirements.

SpecificationDetail
Maximum Dimensions4,500 mm W × 4,750 mm H
Section Filling OptionsWindows, glass, open or blank panel variants
Required Top Clearance1,100 mm
Required Clearance Behind850 mm
Free Installation Depth (top)750 mm
Free Installation Depth (behind)1,000 mm
Required Side Clearance95 mm
Required Operating Side Clearance360 mm
Standard ColourAnodised aluminium or any RAL colour on request
Wind Load RatingClass 4
Water Load RatingClass 3
Air PermeabilityClass 3
Heat Insulation3.84 W/m²K
DriveElectrical
Operating EquipmentStandard control box with optional upgrades
