Gas Tight Doors

Airtight doors engineered for fruit ripening chambers and controlled storage environments. Available in panel, flex and sectional configurations with multi-flap gasket perimeter sealing.

Need a Quote or Door Advice?

Our Door-Rite specialists can assist with door selection, sizing, installation planning, and compliance requirements across South Africa and Africa.

Speak to an Engineer →

Gas Tight Doors are designed for controlled environments such as fruit ripening chambers, cold stores and specialist storage rooms. These doors offer reliable gas retention, precise environmental control and durable construction suitable for facilities that require strict atmospheric conditions. Gas tightness is achieved through multi-flap perimeter gaskets, specialised panel connections or flexible sealing systems depending on the chosen model.

This product range includes three variants to suit different spatial constraints and operational needs: Gas Tight Panel Doors constructed from insulated sandwich panels, Gas Tight Flex Doors using a rolling PVC and polyurethane leaf, and Gas Tight Sectional Doors for applications requiring standard overhead track configurations.

General

  • Suitable environments: storage rooms and fruit ripening chambers including tropical fruit and bananas
  • Gas-tight perimeter sealing
  • Compatible with ripening room control systems
  • Safety features available depending on model

Gas Tight Panel Doors

  • Panel thickness options: 40 mm, 80 mm, 100 mm
  • Construction: insulated sandwich panels with polyurethane foam core
  • Internal and external sheet: 0.5 mm galvanised coated steel
  • Standard colours: 40 mm panels in various colours; 80 mm and 100 mm in RAL 9010 and RAL 9002
  • Kick-out emergency exit window included
  • Electric operation: motor mounted directly on shaft with safety systems

Gas Tight Flex Doors

  • Door leaf material: 1 mm PES fabric with 4 mm polyurethane insulation
  • Operation: flexible rolling door around a steel cylinder
  • Sealing: pneumatic cylinder activated after closure
  • Side guides: aluminium
  • Temperature range: −30°C to +70°C
  • Safety radar strips standard to 2.5 m
  • Leaf colour: standard white with optional full colour printing

Gas Tight Sectional Doors

  • Thickness options: 40 mm or 80 mm
  • Panel construction: insulated sandwich sections
  • Track configurations: horizontal, vertical or pitch-following
  • Internal colour: RAL 9002; external in standard colour range
  • Kick-out emergency exit window included
  • Electric operation with bottom safety edge and slack cable protection
